Automatic hammer operation
Provides blank firing protection by stopping piston movement when no material is beneath the tool. An internal buffering system helps reduce machine vibration, and standard silencing supports operation in noise-regulated environments.
Adjustable impact control
Allows operators to select high piston speed or maximum power settings. An oil-fired operating cycle delivers power with each blow, while critical hydraulic components are protected within the hammer housing.
Simplified service design
Includes standard onboard autolube for continuous greasing during operation. Features a slip-fit, 90-degree rotatable lower bushing for field replacement, an oil-fired design that eliminates gas charge checks, and convenient maintenance access points.
Integrated asset tracking
Cat asset tracking is available on all hammers. Attachment location and status can be monitored in VisionLink™, and geofence alerts can be configured when assets leave designated site boundaries.
| Product Specifications | |
|---|---|
| Blows per Minute | 350 to 620 |
| Minimum Operating Weight | 1480 kg (3256 lb) |
| Rated Flow - Minimum | 100 L/min (26 gpm) |
| Rated Flow - Maximum | 170 L/min (45 gpm) |
| Minimum Operating Pressure | 13000 kPa (1885 psi) |
| Maximum Operating Pressure | 15000 kPa (2175 psi) |
| Tool Shaft Diameter | 120 mm (4.7 in) |
| Minimum Carrier Weight | 16 t (35300 lb) |
| Maximum Carrier Weight | 27 t (59500 lb) |
