Ideal for clearing parking lots, industrial plants, mill yards, airport runways, streets, driveways and lanes.
Variable Sweeping Angle
Angles hydraulically or manually 30 degrees left or right; will also clean in straight position.
Unique suspension system eliminates the need for support wheels. Brush maintains constant ground pressure through a range of vertical motion from the initial setting.
Parking supports provide stable and secure parking of the broom when not in use.
Leveling indicator allows operator to conveniently see the level of the broom from the cab during operation.
Protected Hydraulic Motors
Hydraulic motors are protected form dust and debris
- yet are easily accessible if needed.
Optional Water Kit
An optional water sprinkler kit is available which helps reduce the amount of airborne dust during your sweeping operations.
Polypropylene and Wire Bristle Options
Cat® Angle Brooms come standard with a 50/50 mix of replaceable polypropylene and steel wire sections. Convoluted bristle sections can be converted to all wire or all poly for special applications.
Tool Mounted Operation and Maintenance Manual (OMM) Holder
Tool mounted and sealed from the elements, this holder includes all of the operation manuals and maintenance guides required for proper operation of the work tool.
|Overall Width||3200 mm (126 in)|
|Sweeping Width||3000 mm (118 in)|
|Brush Diameter||915 mm (36 in)|
|Required Hydraulics||Standard Flow|
|Height||1565 mm (61.6 in)|
|Length||1705 mm (67.1 in)|
|Weight||595 kg (1312 lb)|
|Optimal Hydraulic Flow||42-300 L/min (11-79 gpm)|
|Optimal Hydraulic Pressure||150-260 bar (2176-3771 psi)|
|Motor Displacement||310 cmu00b3/rev (19 inu00b3/rev)|
|Brush Speed at Maximum Flow||450 rpm|
|Sweeping Width - Angled (u00b1 30 Degrees)||2165 mm (85.2 in)|
|Overall Width - Angled (u00b1 30 Degrees)||2434 mm (95.8 in)|
|Drive Method||Direct Drive|
|Interface Type||Tool Interface|
