Enquire about "BA25 Manual Angle Broom" Now
Ideal for clearing parking lots, industrial plants, mill yards, airport runways, streets, driveways and lanes.
Variable Sweeping Angle
Angles hydraulically or manually 30 degrees left or right; will also clean in straight position.
Unique suspension system eliminates the need for support wheels. Brush maintains constant ground pressure through a range of vertical motion from the initial setting.
Parking supports provide stable and secure parking of the broom when not in use.
Leveling indicator allows operator to conveniently see the level of the broom from the cab during operation.
Protected Hydraulic Motors
Hydraulic motors are protected form dust and debris
- yet are easily accessible if needed.
Optional Water Kit
An optional water sprinkler kit is available which helps reduce the amount of airborne dust during your sweeping operations.
Polypropylene and Wire Bristle Options
Cat® Angle Brooms come standard with a 50/50 mix of replaceable polypropylene and steel wire sections. Convoluted bristle sections can be converted to all wire or all poly for special applications.
Tool Mounted Operation and Maintenance Manual (OMM) Holder
Tool mounted and sealed from the elements, this holder includes all of the operation manuals and maintenance guides required for proper operation of the work tool.
|Overall Width||2700 mm (106.3 in)|
|Sweeping Width||2500 mm (98.4 in)|
|Brush Diameter||700 mm (27.6 in)|
|Required Hydraulics||Standard Flow|
|Height||1300 mm (51.2 in)|
|Length||1770 mm (69.7 in)|
|Weight||460 kg (1014 lb)|
|Optimal Hydraulic Flow||40-150 L/min 11-40 gpm)|
|Optimal Hydraulic Pressure||150-205 bar (2176-2973 psi)|
|Motor Displacement||195 cmu00b3/rev (12 inu00b3/rev)|
|Brush Speed at Maximum Flow||380 rpm|
|Sweeping Width - Angled (u00b1 30 Degrees)||2165 mm (85.2 in)|
|Overall Width - Angled (u00b1 30 Degrees)||2434 mm (95.8 in)|
|Drive Method||Direct Drive|
|Interface Type||IT Coupler|
