830 mm (33 in) Nordic Digging Bucket

  • Overview
CALCULATE FINANCE

Application

Designed to create maximum performance in combination with an S Type quick coupler and/or tiltrotator.

Short Tip Radius and Long Floor

With high breakout forces combined with tiltrotator usage, the bucket still produces acceptable bucket volumes.

Torque Tube

For low build bracket solution, close to zero offset and high bending resistance even during high stress work.

Wear Protected Side Plates

Specially designed side wear plates provide for optimal wear resistance in heavy duty applications.

Wear Strips

For high resistance against wear even during the most demanding work environments.

Product Specifications
Width 830 mm (32.7 in)
Capacity 400 l (14.1 ftu00b3)
Weight 292 kg (643.7 lb)
Base Edge Thickness 25 mm (1 in)
Tip Radius 1147 mm (45.2 in)
Interface Type S-50 Coupler
