CB2.9 Utility Compactor

  • Overview
  • Finance With CavPower
  • Optional Services
  • View product Download
CALCULATE FINANCE

Simple Operation

Efficient Compaction Performance

Best_In_Class Water Spray System

Optimized Power

Weights
Maximum Operating Weight 3278 kg (7230 lb)
Operating Specifications
Static Linear Load 12.4 kg/cm (69.5 lb/in)
Drum Offset 40 mm (1.5 in)
Travel Speed - Maximum 12 km/h (7.5 mile/h)
Standard Compaction Width 1300 mm (51 in)
Engine
Gross Power 22.9 kW (30.7 HP)
Engine Model C1.5
Dimensions
Overall Width 1412 mm (56 in)
Height - ROPS 2700 mm (106 in)
Wheel Base 1800 mm (71 in)
Overall Length 2575 mm (101 in)
Vibratory System
Nominal Amplitude - High 0.56 mm (0.022 in)
Centrifugal Force per Drum - Minimum 15.5 kN (3485 lb)
Centrifugal Force per Drum - Maximum 34.9 kN (7846 lb)
Frequency 60/48 Hz (3,600/2,880 vpm)
Service Refill Capacities
Water Spray Tank Capacity 200 l (52.8 gal (US))
Fuel Tank Capacity 60 l (15.9 gal (US))
Weights
Operating Weight 2700 kg (5952 lb)

Optional Equipment

  • Ballast
  • Battery Disconnect Switch
  • Bio-hydraulic Oil
  • Bumpers
  • Canopy, Folding
  • Cup Holders
  • Custom Paint
  • Dual Propel Levers
  • Edge Cutter Ready
  • LED Lights
  • ROPS, Folding
  • Seat w/Operator Presence Switch
  • Sliding Seat
  • Traction Control
