1.3 m3 (1.7 yd3) General Purpose Bucket with bolt-on cutting edge
Designed for digging, loading, carrying, leveling, grading and dumping in a variety of applications and materials. These all purpose buckets are ideal for construction, landscaping, industrial and more aggressive demolition applications.
Long bucket floor length, combined with large radius back wrapper, provides superior material loading and dumping, resulting in greater payloads and quicker cycle times.
Upper and lower torque tubes and thick side walls provide added strength and increased durability in aggressive applications.
Strong and Durable
Hardened front base edge and side cutters provide excellent penetration, durability and wear life.
Ground Engaging Tool Options
Base bucket also available with bolt-on cutting edge and bolt-on teeth.
|Width||2080 mm (81.9 in)|
|Weight||462.1 kg (1018.8 lb)|
|Height||984 mm (38.7 in)|
|Length||1066 mm (42 in)|
|Capacity||1.3 mu00b3 (1.7 ydu00b3)|
|Base Edge Thickness||20 mm (0.8 in)|
|Cutting Edge Thickness||16 mm (0.6 in)|
|Interface Type||ISO Coupler|
